How Keen Is Your Rank? is an episode of the Degrees of Freedom Project, The Full Story videos on chemical and thermal principles with additional in-depth discussion. If you want the Just The Facts version without additional discussion, use the link in the description. Definitions and additional details can be found in the web-page link in the description as well.

  • This Video – How Keen Is Your Rank? explains how to convert temperatures and temperature intervals.
  • Another Video – Is Furlongs Per Fortnight a Thing? explains how to convert a measured or calculated quantity from one set of units to another (except for temperatures).
  • A Third Video – The Most Annoying Equation Conversion explains how to convert an equation as opposed to a calculated or measured quantity from one set of units to another.

What are the common units of temperature used in Chemical and Thermal Processing?

What temperature scales do we use?

\(\bullet\) Kelvin, K

\(\bullet\) Celsius, °C

\(\bullet\) Fahrenheit, °F

\(\bullet\) Rankine, °R

\(\mathbf{-}\) absolute scale (starts at zero)

\(\mathbf{-}\) absolute scale (starts at zero)

\(\mathbf{-}\) used when working with gases in Am. Eng. Units

What two common temperature scales are absolute scales, starting at absolute zero?

What is the difference between the temperature of an object and a temperature interval?

Temperatures vs. Temperature Intervals

  • Temperature: the single temperature of an object
  • Temperature interval: the difference between two temperatures

Temperature
\(32\ \mathrm{^\circ F}\)

Temperature
\(212\ \mathrm{^\circ F}\)

Temperature Interval
\(\longleftarrow\ \ 180\ \mathrm{^\circ F}\ \ \longrightarrow\)

Temperature Equations (1/2)


  • Celsius to Fahrenheit: \(T(\mathrm{^\circ F}) = \frac{9}{5} T(\mathrm{^\circ C}) + 32\)
  • Celsius to Kelvin: \(\ \ \ \ \ \ T(\mathrm{K}) = T(\mathrm{^\circ C}) + 273.15\)
  • Celsius to Rankine: \(\ \ \ T(\mathrm{^\circ R}) = \frac{9}{5} T(\mathrm{^\circ C}) + 491.67\)


  • Fahrenheit to Celsius: \(\ \ T(\mathrm{^\circ C}) = \frac{5}{9}[T(\mathrm{^\circ F}) - 32]\)
  • Fahrenheit to Kelvin: \(\ \ \ T(\mathrm{K}) = \frac{5}{9} [T(\mathrm{^\circ F}) - 32] + 273.15\)
  • Fahrenheit -> Rankine: \(T(\mathrm{^\circ R}) = T(\mathrm{^\circ F}) + 459.67\)

Temperature Equations (2/2)


  • Kelvin to Fahrenheit: \(T(\mathrm{^\circ F}) = \frac{9}{5} T(\mathrm{K}) - 459.67\)
  • Kelvin to Celsius: \(\ \ \ \ \ T(\mathrm{^\circ C}) = T(\mathrm{K}) - 273.15\)
  • Kelvin to Rankine: \(\ \ \ \ T(\mathrm{^\circ R}) = \frac{9}{5} T(\mathrm{K})\)


  • Rankine to Fahrenheit: \(\ T(\mathrm{^\circ F}) = T(\mathrm{^\circ R}) - 459.67\)
  • Rankine to Kelvin: \(\ \ \ \ \ \ \ \ \ T(\mathrm{K}) = \frac{5}{9} T(\mathrm{^\circ R})\)
  • Rankine -> Celsius: \(\ \ \ \ \ \ T(\mathrm{^\circ C}) = \frac{5}{9}[T(\mathrm{^\circ R}) - 491.67]\)

Temperature Interval Equations

\(\Delta\)Celsius to \(\Delta\)Fahrenheit: \(\Delta T(\mathrm{^\circ F}) = \frac{9}{5} \Delta T(\mathrm{^\circ C})\)

\(\Delta\)Celsius to \(\Delta\)Kelvin: \(\ \ \ \ \ \ \ \Delta T(\mathrm{K}) = \Delta T(\mathrm{^\circ C})\)

\(\Delta\)Celsius to \(\Delta\)Rankine: \(\ \ \ \ \Delta T(\mathrm{^\circ R}) = \frac{9}{5} \Delta T(\mathrm{^\circ C})\)

\(\Delta\)Fahrenheit to \(\Delta\)Celsius: \(\ \ \Delta T(\mathrm{^\circ C}) = \frac{5}{9} \Delta T(\mathrm{^\circ F})\)

\(\Delta\)Fahrenheit to \(\Delta\)Kelvin: \(\ \ \ \ \Delta T(\mathrm{K}) = \frac{5}{9} \Delta T(\mathrm{^\circ F})\)

\(\Delta\)Fahrenheit to \(\Delta\)Rankine: \(\Delta T(\mathrm{^\circ R}) = \Delta T(\mathrm{^\circ F})\)

\(\Delta\)Kelvin to \(\Delta\)Fahrenheit: \(\Delta T(\mathrm{^\circ F}) = \frac{9}{5} \Delta T(\mathrm{K})\)

\(\Delta\)Kelvin to \(\Delta\)Celsius: \(\ \ \ \ \ \Delta T(\mathrm{^\circ C}) = \Delta T(\mathrm{K})\)

\(\Delta\)Kelvin to \(\Delta\)Rankine: \(\ \ \ \Delta T(\mathrm{^\circ R}) = \frac{9}{5} \Delta T(\mathrm{K})\)

\(\Delta\)Rankine to \(\Delta\)Fahrenheit: \(\Delta T(\mathrm{^\circ F}) = \Delta T(\mathrm{^\circ R})\)

\(\Delta\)Rankine to \(\Delta\)Kelvin: \(\ \ \ \ \ \ \ \Delta T(\mathrm{K}) = \frac{5}{9} \Delta T(\mathrm{^\circ R})\)

\(\Delta\)Rankine to \(\Delta\)Celsius: \(\ \ \ \ \ \Delta T(\mathrm{^\circ C}) = \frac{5}{9} \Delta T(\mathrm{^\circ R})\)

Example 1 - Temperature (1/2)

Convert \(5\ \mathrm{^\circ C}\) into Kelvin, Fahrenheit, and Rankine.

  • \(5\ \mathrm{^\circ C} \implies ?\ \mathrm{K}\)
    • Remember: \(T(\mathrm{K}) = T(\mathrm{^\circ C}) + 273.15\)
    • \(\implies T(\mathrm{K}) = 5\ \mathrm{^\circ C} + 273.15= 278.15\ \mathrm{K}\)


  • \(5\ \mathrm{^\circ C} \implies ?\ \mathrm{^\circ F}\)
    • Remember: \(T(\mathrm{^\circ F}) = \frac{9}{5} T(\mathrm{^\circ C}) + 32\)
    • \(\implies T(\mathrm{^\circ F}) = \frac{9}{5}(5\ \mathrm{^\circ C})+ 32 = 41\ \mathrm{^\circ F}\)

Example 1 - Temperature (2/2)

Convert 5 °C into Kelvin, Fahrenheit, and Rankine.

  • \(5\ \mathrm{^\circ C} \implies ?\ \mathrm{^\circ R}\)
    • Remember: When converting from Celsius to Rankine, we prefer to first convert to Kelvin, then Rankine.
    • We can use what we got from our first conversion, \(T(\mathrm{K}) = 278.15\ \mathrm{K}\)
    • \(\implies T(\mathrm{^\circ R}) = \frac{9}{5}(278.15\ \mathrm{K}) = 500.67\ \mathrm{^\circ R}\)

Example 2 - Temp. & Temp. Intervals (1/2)

Over a limited temperature range, the heat capacity of liquid acetone is

\(C_p \left[\mathrm{\frac{kJ}{mol \cdot ^\circ C}} \right] =0.1230+0.000186T\) where \(T\) is in \(\mathrm{^\circ C}\).

What are the heat-capacity formulas with \(T\) in \(K\), \(\mathrm{^\circ R}\), and \(\mathrm{^\circ F}\)?

To Kelvin
\(C_p \left[\mathrm{\frac{kJ}{mol \cdot K}} \right]\mathrm{\frac{1\ K}{1\ \mathrm{^\circ C}}} =0.1230+0.000186(T-273.15)T\) where \(T\) is in \(\mathrm{K}\).

\(\implies C_p \left[\mathrm{\frac{kJ}{mol \cdot K}} \right] =0.0722+0.000186T\) where \(T\) is in \(\mathrm{K}\).

Example 2 - Temp. & Temp. Intervals (2/2)

To Rankine
\(C_p \left[\mathrm{\frac{kJ}{mol \cdot ^\circ R}} \right]\mathrm{\frac{9\ ^\circ R}{5\ \mathrm{^\circ C}}} =0.1230+0.000186 \left( \frac{5}{9}[T-491.67] \right)\) where \(T\) is in \(\mathrm{^\circ R}\).

\(\implies C_p \left[\mathrm{\frac{kJ}{mol \cdot ^\circ R}} \right] =0.04011+0.00005741\) where \(T\) is in \(\mathrm{^\circ R}\).

To Fahrenheit
\(C_p \left[\mathrm{\frac{kJ}{mol \cdot ^\circ F}} \right]\mathrm{\frac{9\ ^\circ F}{5\ \mathrm{^\circ C}}} =0.1230+0.000186 \left( \frac{5}{9}[T-32] \right)\) where \(T\) is in \(\mathrm{^\circ F}\).

\(\implies C_p \left[\mathrm{\frac{kJ}{mol \cdot ^\circ F}} \right] =0.06650+0.00005741\) where \(T\) is in \(\mathrm{^\circ F}\).

The Takeaways

  1. There are four common temperature scales:
  • Kelvin, Rankine, Fahrenheit, and Celsius
  1. The conversions between temperatures are different from the conversion of temperature intervals.
  2. Most temperature conversions requre both multiplication and addition/subtraction.
  • Conversion between Rankine and Kelvin only require multiplication
  1. All of the temperature-interval conversions just require multiplication by 9/5, 5/9, or 1.
